8
RemoteMix 4™ Broadcast Field Mixer
Pairing Mode
In Pairing Mode, any Bluetooth wireless technlogy enabled device within
range can pair with your RemoteMix 4. To put the unit in Pairing Mode, pull
up the < > switch for 5 seconds while the unit is on. The blue LED will
flash rapidly at a rate of 100ms off, 100ms on. Once the pairing process is
complete the unique device ID is stored in Connection History. Subsequent
connections can be made automatically from Idle Mode.
Idle Mode
In Idle Mode, RemoteMix 4 searches for paired devices. To put the unit in Idle
Mode, pull up the < > switch for 2 sec when the unit is on. The blue LED will
flash at a rate of 2 secs off, 200ms on.
Connected Mode
After bonding is complete, the blue LED will flash at a slower rate of 2 secs
off, 1 sec on. The connection to that device is secure.
Bluetooth Status LED
The blue LED on the front of the unit flashes in different sequences to indicate
the current connection status. When attempting to put the unit into Idle or
Pairing mode, you should power the unit off then back on before pressing
the < > switch. If you put the unit into the wrong state due to releasing the
< > switch at the wrong time, holding the < > switch for "X" seconds will not
put it into the desired mode.
When Should I Release the Switch?
Idle Mode Pairing Mode Role Change Clear
Bluetooth LED
seconds
Pairing to a Device with Bluetooth Wireless Technology
1. Set your Bluetooth device to Pairing Mode following the
manufacturer’s instructions.
2. On the RemoteMix 4, pull up on the switch < > and hold for approximately
5 seconds. The blue LED will begin to flash rapidly as RemoteMix 4 enters
Pairing Mode. Pairing Mode will time out in 2 minutes.
3. On your Bluetooth device, from the list of Bluetooth connections, select
“JKRM4xxxx” where “xxxx” corresponds to the last 4 digits of the
unit’s serial number. Enter “Yes” when asked to bond with this device.
The pin is “0000”.
4. When bonding is completed, the blue LED will flash at a rate of 2 secs off,
1 sec on.
Bluetooth Wireless Technology
