Controls & Indicators
3
6.
Cue Control
The
the 1/4”
the individual headphone level control adjusts the overall level of your
headphones while the
on the other side of the call in all headphones. You should keep in mind
that your wireless telephone also has level control. If you are having level
problems that cannot be corrected with the controls on the RemoteMix 4,
try adjusting the level on the wireless telephone itself.
7.
Bluetooth Wireless Technology
This switch activates the Bluetooth Wireless Technology. The blue LED
directly above this switch indicates when it is on.
8.
Keypad Switch
This switch disables the DTMF keypad to prevent unwanted tones from
being transmitted down the phone line during a broadcast.
9.
Ringer
RemoteMix 4 does not have an audible ringer but there is a visual ring
indicator that will flash for incoming calls. This red LED is located directly
below the keypad.
10.
Phone Line Switch
When using the RJ-11 analog phone jack, this switch acts as the switch-
hook for the telephone line. The On Hook position is when you are not
using the line or you are waiting for a call. When you want to place a call,
or when a call comes in, switch to the Dial/Talk position.
11.
Power
This is the main power switch that turns the unit on. Whenever the power
is turned on, the red LED above this switch will be lit. The green
LED will be lit whenever a live AC power source is connected, even if the
main power switch is off.
Getting to Know Your RemoteMix 4
6
7
8
9
10
11
Controls & Indicators Cont’d
