6
Features—Rear View
9. Phone Line - Connect only to a standard, single line, analog
telephone line.
10. Aux. Phone - Connect a single line analog telephone for call
setup / dialing, or producer call screening.
11. Auto Answer - This button enables innkeeper LTD to auto-
matically answer an incoming call and then disconnect after the
caller hangs up. Auto Answer will occur on the first ring.
12. Caller Output - Male balanced XLR line level output contains
only the caller’s voice.
13. Send Input - Female balanced XLR line level input for signals
going out to the phone line.
14. Remote Control Jack - 8-pin modular RJ-45 jack for connec-
tion to the optional JK Audio Guest Module 1 Remote Keypad
or your broadcast console switch contacts. Do not connect this
jack to your computer network port.
15. Power - For connection only to the supplied 9VDC regulated
power supply.
15 9 10 12 13 14 11
Figure 2: Back View
