IDX VW-5 - Manual (Page 2)

Table of Contents
Accessories Check-list…………………………………….……………….….. 14
Ⅰ
.SAFETY INSTRUCTIONS…..…………………….……………….………… 15
Ⅱ
.CONTENTS……………………………………….……………….………..……… 17
Chapter 1 Product Overview………………………..……………. 17
Chapter 2 Getting Started…………………………………………. 19
2.1 VW-5TX Transmit unit……...………………… 19
2.1.1 Front Panel View……..…………….… 19
2.1.2 Rear Panel View………………………… 20
2.2 VW-5RX Receive unit……..…………………… 21
2.2.1 Front Panel View……………….…….. 21
2.2.2 Rear Panel View………………………. 22
Chapter 3 Setup Menus…………………………………………….. 23
Chapter 4 Specifications……………………………………………. 24
Chapter 5 Inputs/Outputs…………………………………..…….. 27
Chapter 6 Pairing & Others………………………………..…….. 29
Pairing (Matching) set-up……………..…. 29
Others…………………………………………….…. 29
Accessories Check
VW-5TX VW-5RX
AC Adaptor with power cord AC Adaptor with power cord
AV cable AV cable
S-Video cable S-Video cable
IR cable Holder
Holder SCART adaptor ( for Europe only )
SCART adaptor ( for Europe only )
14
