7. Important notice
1. The available service frequencies and transmission power varies
depending on the designated regions because each region has different
local regulations and restrictions of radio waves. Therefore all the
CW-7s are programmed accordingly to each region, thus, shipment
and usage of the CW-7 in an unspecified region may cause violation of
law.
2. Use of 5GHz band outdoors has been limited by the frequency. CH3,
CH4 and DFS AUTO position allows to outdoor use. When operating
indoor, CH1 and CH2 should be selected.
3. The maximum transmission range depends on the selected frequency,
surrounding environment, radio wave conditions, composition of the
wall, weathering, etc. Thus the specification of the transmission
range is 50m/150ft with POWER MODE HIGH, however this is not a
definite range.
4. When TX and RX are placed too close to each other, the transmission
signal becomes too strong and may disturb the video signal. Please
set the POWER MODE switch on the TX to LOW position in case of
when the distance between TX and RX is 3m or less.
5. CW-7 has a built-in antenna and modification of adding external
antenna is not authorized by IDX. This may affect the performance
of CW-7 and void IDX standard warranty.
6. SDI signal complies with SMPTE-292M/SMPTE-259M however, clock
jitter may exceed the regulated values caused by link condition.
7. SDI embedded audio channels are Ch1 and Ch2.
8. Quality of wirelessly transmitted signal may not be the same as the
quality of when using coaxial cable as the transmission quality varies
by operational conditions and environment.
9. IDX recommends attaching the TX onto the camera with IDX
standard V-Mount adaptor installed. If the V-Mount on the camera is
made by an unknown third party, it may cause an unexpected
malfunction.
