TUV (1/03)
REV. 0.2

1 . 0

IMPORTANT INFORMATION

1.1 HOW TO USE THIS MANUAL

This equipment, while sophisticated, has been designed for simple and easy operation. In keeping
with that philosophy, this TUV Analyzer user’s manual has been written to simplify all steps
in the procedures that follow.

THE MOST IMPORTANT ASPECT OF THIS MANUAL IS THAT YOU, THE USER, READ IT IN
ITS ENTIRETY AND REFER TO IT OFTEN.

Figures and drawings have been used throughout the manual to show you how, and text has been
used to enhance and clarify what you have been shown.

Again, please read the manual before attempting to install or operate the TUV Analyzer. Pay
p a r t i c u l a r a t t e n t i o n t o t h e “ W a r n i n g ” a n d “ C a u t i o n ” m e s s a g e s t h r o u g h o u t . A l t h o u g h t h e
TUV Analyzer is easy to use, all electrical and safety precautions must be followed. “Notes”
have also been added to give further clarification or reminders in certain instances.

1 . 2

SPECIFICATIONS FOR THE TUV ANALYZER

Specification

TUV ANALYZER

Response Time:

Reading is updated every 30 seconds

Microprocessor:

6 8 H C 1 1

Keyboard entry Analyzer:

8 membrane function keys

Built-in diagnostics:

Yes

Analog output:

4 - 20 mA and .1, 1 or 10 Vdc

Alarms:

1 system, 2 settable HI, LO or Off with 2.5, 5.0
or 10% settable deadband

Alarm contact rating:

Max. 250 VAC @ 5.0A resistive, isolated, Form C
(SPDT)

Operating Temperature:

32° - 122°F (0 ° - 50°C)

Storage Temperature:

-4° - 140°F (-20° - 60°C)

Sensor/Sampler-Analyzer Separation:

Depending on site conditions, up to 1000 feet (300m)

Sensor/Sampler-Analyzer
communication:

RS-485 Serial Port, 9600 Baud, Isolated 1.5kv

Analyzer Case Dimensions:

13" x 11 1/2" x 8" (330 x 290 x 200 mm)

Calibration:

Automatic, with calibration periods user selectable

Pollution Degree:

2

Over voltage category :

II

Page 1
