HS-3100/3200 Installation Manual
7
2.0 Technical Specifications
2.1 Electrical Specifications
Table 1: AC Input
Table 2: Battery Power (Use sealed lead acid batteries only!)
a. Maximum current available to the battery charging circuit is limited by the power draw
from additional devices. As the AUX power circuits are loaded, or additional modules are
added, the amount of current available for charging batteries decreases.
b. Reference Appendix B for Battery Calculations and compatible batteries.
Circuit / Model / Item Rating
Standard Primary AC Input 1
HS-3100 120V, 60Hz, 1.03 A maximum
240V, 50Hz, 0.51A maximum
Optional Primary AC Input 2
HS-3200 120V, 60Hz, 2.5 A maximum
240V, 50Hz, 1.26A maximum
Circuit / Model / Item Rating
Battery Charger Current limited float charger
Float charge: 27.5 VDC
Charging current: 2.7A maximum (no auxiliary load),
1.7A nominal (0.5A on each AUX)
Maximum Battery Capacity
Batteries larger than 12Ah require the
use of a listed battery cabinet.
12Ah (max. internal to cabinet)
35Ah (Largest size battery that can
be used, HS-378B,HS-378R External
Battery Cabinet required)
