Express® Lavatory System - MG-Series with TouchTime® Control
MG-2/TT
Installation Instructions
20 2/8/07 Bradley Corporation • 215-1480 Rev. E; EN 06-915
Strainer
173-028
Tempered Line Adapter Assembly (S39-685) Option
Thermostat 5 1
7 1 O-Ring
8 1 O-Ring
Item Qty Description
Repair Kit S65-259
9
6
5
4
3
2
1
7
8
Strainer
(173-028)
Valve Body
Spring
Thermostat
Piston
Stem
O-Ring
O-Ring
Cap
Nut 3/8-24 Hex Jam 10
Seal Cup
11
Figure 13
Figure 14
Vernatherm™ Thermostatic Mixing Valve (S01-524)
