4 Accessories
The MAVOSPEC can be combined with different accessories for various measurement
purposes. The device is equipped with a coder for the automatic detection of an
attached accessory and for automatic calibration file download.
When you purchase your MAVOSPEC with accessories, factory spectral calibration is
included in the price. Simply remove the standard measuring head and you can attach
any add-on to the spectrometer. When connected to the computer, the software will
recognize the unit and automatically download the proper calibration file.
4.1 Integrating Sphere – MAVOSPHERE 48 (M601A)
MAVOSPHERE 48 is an MAVOSPEC accessory for luminous flux measurement of
LEDs and other small light sources.
The set includes the sphere in housing with a coder for automatic detection of the
accessory. It is delivered with the certificate of factory absolute spectral calibration.
Installation and startup
1. Remove the standard measuring head delivered with your MAVOSPEC.
2. Put on the adapter and then attach the sphere in an up-right position.
Use the screw at the bottom of the sphere to firmly fix the add-on.
3. When connected to the computer the system will recognize the unit
and download the proper calibration file.
i If you purchase the accessory separately, remember to send your spectrometer to us for
factory calibration. Separate charges will be applied.
i
If you need to measure bigger light sources, there are a lot of other integrating spheres in
diameters from 205 mm up to 2000 mm available. Please ask for the accessories
MAVOSPHERE 205, MAVOSPHERE 500, MAVOSPHERE 1100, MAVOSPHERE 2000
