GBC BM 200 Bookmaker - Manual (Page 49)

49
8. Specification
Machine Specifications
Booklet Maker BM 200
Specifications Remarks
Capacity 25 sheets of 80 gsm (20 lb. Bond)
Max booklet length, max.
trimming
220 mm (8,6”)
Min booklet length, max.
trimming
120 mm (4,7”)
Max booklet length, by
pass
25 mm (9,2”)
Min booklet length, by
pass
105 mm (4.1”)
Booklet width, max 20 mm (12.6”)
Booklet width, min 120 mm (4,7”)
Speed Up to 1800 sets/hour
Trim length Up to 15 mm (0.6”)
Dimensions incl. base, H
x W x D
910 x 50 x 620 mm (5.8 x 1.8 x 24.4”)
Weight 65 kgs (144 lbs.)
Power Source From BM 200
Specifications Remarks
Capacity 25 sheets of 80 gsm (20 lb. Bond)
Speed Up to 000 sets/hour
Sheet size, max 20 x 457 mm (12.6 x 18”)
Sheet size, min 206 x 275 mm (8.1 x 10.8”)
Standard Sheet Sizes A4, A, B4, 8.5x11”, 8.5x14”, 11x17” Custom sizes are available
Paper weight, max 00 gsm (115 lb. Cover)
Paper weight, min 64 gsm (18 lb. Bond)
Stapler heads 2
Staples 2 x 5000 Chisel pointed
Job saving Yes, 10 jobs
Dimensions incl. base and
belt stacker, H x W x D
1000 x 1420 x 670 mm (9.4 x 55.9 x 26.4”)
Weight 10 kgs (287 lbs.)
Power Source 100 / 110 / 115 / 127 / 220 / 20 50-60Hz + - 10%
Power consumption 200 W or less Continuous Operations
Trimmer fTR 200 (option)
