Oil clinchers
This message will be displayed every 20 000 stapling cycles. The purpose is to remind the
operator to maintain stapler head and clinchers. If not doing that every 20 000 there is a great
risk of a costly mechanical breakdown. See section Maintaining Your Machines on page 46
for procedure.
Fault codes
stacker full
This message will be displayed when the when the belt stacker on the Booklet Maker is full.
Empty the belt stacker, select Manual mode again (see page 27) and continue hand feeding
or press the start button on the Collator to continue the job.
Check set
This message will be displayed when a calibration set is sent from the Collator. The calibration
set is stopped in the Booklet Maker, providing the possibility to check the set before it is being
stapeled and folded. The operator now have three choices.
Open the Booklet Maker top cover and check that the set is okay. The set can be removed
from the Booklet Maker if the operator so wishes. Close the Booklet Maker top cover and
press the start button on the Collator to start the job.
Press the purge button on the Collator. Check that the set fed to the belt is okay and
press the start button on the Collator to start the job.
Press the start button on the Collator to start the job.
Booklet Maker fault codes, continues
Trimmer fault codes
Empty trim bin
This message will be displayed when the trim bin is full or when a trim strip, due to static
electricity, is prevented from falling down into the trim bin. Empty the trim bin and remove loose
trim strips from inside the Trimmer. See section 1. Basics for how to remove the trim bin.
Close trimmer belts
This message will be displayed when the when either trimmer belt is in the lifted position. Make
sure that both the infeed roller shaft and the exit compressing brackets are in the operating
position, see section 5, Trimmer, Clearing Misfeed(s).
