Infeed section collator side – GBC 61 Plackmatic Bookmaker User Manual

Page 13

background image

T10165

OPERATOR MANUAL BM 61

1

Positioning holes, small paper width

(Used for A4/8”

1

/

2

paper widths or sizes

nearby)

Positioning holes, large paper width

(Used for A/11” paper widths or sizes nearby)

Positioning mark (green)

(Shall correspond to the green mark on the

Collator)

Paper stop crank

(Used for adjustment to correct paper length)

Rear jogger latch

(Used to lower the rear jogger and enable

OFF-line operation)

Rear jogger adjustment latch

(Used to position the rear jogger to the paper

length)

Receptacle, connection cable

(The connection cable from the Collator

connects here)

Knob, adjustment for odd paper size

(By loosening the knob the Docking Bracket

can be individually positioned for odd paper

sizes)

Docking Bracket

1.

2.
.

4.
5.

6.

7.

8.

9.

1

2

4

5

6

7

8

9

3.3 Infeed section, collator side
