5. Clearing a Paper Jam
8
Trimmer
Clearing a Paper Jam
Lift up the infeed roller shaft (A).
Secure under latch (B)
Remove the jammed sheets in the infeed area.
After the jammed sheets are removed, lift up the latch (B) and place the infeed roller
shaft in the operating position.
Clearing Jam in Input Area
The upper trimmer blade on the trimmer is protected by a knife protection plate that moves
away during the cutting stroke. Jams can occur in the input area or the exit area.
WARnInG:
Never put fingers or other parts of the body between the upper and lower trimmer knives.
B
A
Infeed roller shaft,
operating position
Infeed roller shaft,
lifted position
