E-flite Viking Model 12 280 BNF Basic User Manual
Page 3
3
EN
To register your product online, go to www.e-fl iterc.com
Table of Contents
Installed
BL 280 Outrunner Motor, 1800Kv
(EFLM7010)
BL Controller, 10A (EFLA7300)
AR6335 6-Channel AS3X
®
Nanolite
Receiver, Air (SPMAR6335)
(4) 3.5 g Digital Servo (EFLR7100 and
EFLR7100L)
Need to Complete
450mAh 3S 11.1V 30C LiPo,
18AWG JST (EFLB4503SJ30)
Recommended Battery Charger:
Prophet
™
Sport Plus 50W AC DC
Charger (DYNC2010CA)
Recommended Transmitter:
Full Range
DSM2
®
/DSMX
®
technology with adjustable
dual rate and exponential (DX4e and up)
24.4 in (620mm)
22.2 in (565mm)
8.80 oz
(250 g)
Box Contents
Specifi cations
Transmitter Setup .................................................4
Prefl ight Checklist .................................................5
Assembly ..............................................................5
Transmitter and Receiver Binding .........................7
Battery Installation ................................................8
ESC Arming ..........................................................8
Control Direction Test ...........................................9
AS3X Control Direction Test ..................................9
Control Centering ...............................................10
Control Horn and Servo Arm Settings ..................10
Center of Gravity (CG) .........................................11
Low Voltage Cutoff (LVC) .....................................11
Flying Tips and Repairs .......................................12
Post Flight Checklist ...........................................12
Service of Power Components ............................13
Troubleshooting Guide ........................................13
Limited Warranty ................................................15
Warranty and Service Contact Information ..........16
FCC Information ..................................................16
Compliance Information for the European Union ..16
Replacement Parts ..............................................62
Optional Parts and Accessories ...........................63
Wing Area: 197.0 sq in
(12.7 sq dm)
