1. Locate the landing gear assembly. Attach the

landing gear assembly to the fuselage using
three 4-40 x 1/2" socket head screws.

Note:.The.landing.gear.will.only.fit.one.

direction.for.the.holes.to.line.up.properly.

Landing Gear Installation

Required Parts

• Fuselage

• Landing gear assembly with wheels

• 4-40 x 1/2" socket head screw (3)

Required Tools

• Hex wrench: 3/32"

12
