Series 2000, Two-way flow checks, For hydronic heating applications

Series 2000
Two-Way Flow Checks
Sizes:
3
/
4
"-3" (20-80mm)
Series 2000 Two-Way Flow Checks are designed to provide
positive gravity shutoff when circulator is not running. These
checks are easily opened for gravity circulation.
Models
2000-M5 –
3
/
4
"-3" (20-80mm) horizontal and angle checks.
Iron body construction. Sizes
3
/
4
"-1
1
/
2
" (20-40mm) have female
threaded connections. Sizes 2"-3" (50-80mm) have one
flanged outlet x two female threaded connections. One con-
nection can be used for the installation of an expansion tank
when installed as an angle check.
2000S-M5 –
3
/
4
"-1" (20-25mm) straight pattern. Bronze body
construction, solder inlet and outlet connections.
Specifications
Flow checks shall be installed on forced hot water heating sys-
tems where indicated on the plans to provide positive gravity
shutoff when circulator is not running. Checks shall be easily
opened for gravity circulation. Threaded end connection
checks shall have an iron body and solder end connection
checks shall have a bronze body. Check shall be a Watts
Regulator Company Series 2000.
Pressure – Temperature
Sizes
3
/
4
"-1
1
/
4
" (20-32mm)
Maximum Working Pressure – 50psi (344.8 kPa)
Temperature Range 33ºF - 250ºF (5ºC - 121ºC)
Sizes 1
1
/
2
"-3" (40-80mm)
Maximum Working Pressure – 125psi (8.6 bars)
Temperature Range 33ºF - 250ºF (5ºC - 121ºC)
Materials
Model 2000-M5
Body: Iron
Seat: Bronze
Center Guide: Brass
Model 2000S-M5
Body: Bronze
Seat: Bronze
Center Guide: Brass
For Hydronic Heating Applications
ES-2000
Job Name –––––––––––––––––––––––––––––––––––––––––––
Contractor ––––––––––––––––––––––––––––––––––––––––––––
Job Location –––––––––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Engineer –––––––––––––––––––––––––––––––––––––––––––––
Contractor’s P.O. No. –––––––––––––––––––––––––––––––––––
Approval –––––––––––––––––––––––––––––––––––––––––––––
Representative ––––––––––––––––––––––––––––––––––––––––
Watts product specifications in U.S. customary units and metric are approximate and are provided for reference only. For precise measurements,
please contact Watts Technical Service. Watts reserves the right to change or modify product design, construction, specifications, or materials with-
out prior notice and without incurring any obligation to make such changes and modifications on Watts products previously or subsequently sold.
2000-M5
3/
4
"-1
1
/
2
"
2000S-M5
3/
4
"-1"
2000-M5
2", 2
1/
2
", 3"
