MODEL CONNECTIONS DIMENSIONS WEIGHT
Size A B C D E
inlet outlet in. mm in. mm in. mm in. mm in. mm in. mm lbs. kgs.
RPVM1-S solder solder 3 ⁄
4
" 20 3 5 ⁄
16
84 2 1 ⁄
16
52 3 3 ⁄
16
81 7 ⁄
8
22 4 102 1.0 0.5
RPVM1-S solder solder 1" 25 4 102 2 7 ⁄ 16 62 3 3 ⁄ 16 81 1 1 ⁄ 16 27 4 1 ⁄ 4 108 1.5 0.7
RPVM1-S solder solder 1 1 ⁄
4
" 32 4 3 ⁄
8
111 2 9 ⁄
16
65 3 5 ⁄
16
84 1 3 ⁄
16
30 4 1 ⁄
4
108 2.0 0.9
RPVM1-ST solder FPT 3 ⁄
4
" 20 3 1 ⁄
8
79 2 1 ⁄
16
52 3 1 ⁄
4
83 7 ⁄
8
22 4 102 1.1 0.5
RPVM1-ST solder FPT 1" 25 3 3 ⁄
4
95 2 7 ⁄
16
62 3 3 ⁄
16
81 1 1 ⁄
16
27 4 1 ⁄
4
108 1.6 0.7
RPVM1-ST solder FPT 1 1 ⁄
4
" 32 4 1 ⁄
8
105 2 1 ⁄
2
64 3 5 ⁄
16
84 1 3 ⁄
16
30 4 1 ⁄
4
108 2.0 0.9
A
Dimensions – Weights
ES-RPVM1 1127 © 2011 Watts
USA: No. Andover, MA • Tel: (978) 688-1811 • Fax: (978) 794-1848 • www.watts.com
Canada: Burlington, ON • Tel: (905) 332-4090 • Fax: (905) 332-7068 • www.wattscanada.ca
A Watts Water Technologies Company
C
D
E
B
A
C
D
E
B
RPVM1-ST RPVM1-S
