Bowflex.Xtreme
®
.SE.Assembly.Manual
Parts Reference Guide
ITEM QTY.
DESCRIPTION
1
4
FOOT,.END.CAP,.FRAME
2
1
BASE.FRAME
3
1
RIGHT.FRAME.RAIL
4
1
LEFT.FRAME.RAIL
5
1
REAR.CROSSMEMBER
6
1
ABDOMINAL.BRACKET
7
1
LAT.CROSS.BAR.W/.PULLEYS
8
1
UPPER.LAT.TOWER
9
1
RIGHT.PULLEY.ARM
10
1
LEFT.PULLEY.ARM
11
1
LOWER.LAT.TOWER.FRAME
12
1
SQUAT.PULLEY.FRAME..
13
1
SEAT.BACKBONE
14
1
SEAT.SUPPORT.RAIL
15
4
PULLEY.SLIDER
16
22
BUTTON.HEAD.CAP.SCREW.
.0375-16X0 .75.G2
17
1
BUTTON.HEAD.CAP.SCREW..
0375-16X5.G2
18
2
BUTTON.HEAD.CAP.SCREW..
0375-16X3.G2
19
.2
BUTTON.HEAD.CAP.SCREW..
03125-18X2 .5.G2
20
4
BUTTON.HEAD.CAP.SCREW..
03125-18X0 .75.G2
21
3
FLAT.WASHER.0250.
22
6
FLAT.WASHER.0313
23
32
FLAT.WASHER.0375
24
4
FLAT.WASHER.0500
25
3
PHILLIPS.SCREW.0250-20X1
ITEM QTY.
DESCRIPTION
26
2
TS.0 .500-13X9 .5X .625X .750.BLK
27
5
LOCK.NUT.0375-16.G2
28
4
LOCK.NUT.0500-13.G2
29
1
LOCK.KNOB
30
1
CAP,.BOLT.COVER,.PLASTIC
31
1
BUTTON.HEAD.CAP.SCREW..
.375-16X3X1
32
2
FW-TYPE.B-R.0 .375-BLK
33
1
NUT,.NYLOCK.3/8-16
34
1
LEG.EXTENSION.BACKBONE.
ASSEMBLY
35
2
CHROME.TUBE,.FOAM.ROLLER
36
4
FOAM.ROLLER
37
4
END.CAP,.3/4.INCH
38
1
PIN,.BALL.DENTENT,.LEG.EXT
39
1
BOWFLEX.ROD.PACK.210#
40
1
XTREME.SE.SEAT.ASSEMBLY
41
1
XTREME.SE.SEAT.BACK.ASSEMBLY
42
1
LEG.EXTENSION.ASSEMBLY.PIVOT.
TUBE
43
1
BAR..50”.BENT.LAT.BAR
44
1
BAR.48”.LONG.WITH.FOAM.GRIPS
45
1
ACC.BAG.LEG.#1.ASSEMBLY
46
1
PVC.HANDGRIP.PAIR.ASSEMBLY
47
1
AB.CRUNCH.STRAP.ASSEMBLY
48
1
BRKT,.AB.CRUNCH
49
2
BUTTON.HEAD.CAP.SCREW.
.0375-16X2 .75.G2-BlkO
50
4
FLAT.WASHER.0375.NARROW
51
1
XTREME.SE.AB.BRKT.TUBE.ASSY
