Page 14

Bowflex.Xtreme

.SE.Assembly.Manual

Step 8...Install.Slider.Pulleys

parts:

.•...2.Slider.Pulleys.with.Cable.Assembly

•...Main.Assembly

tools:

3/16.Hex.Wrench

8-1

...Install.a.Slider.Pulley.onto.each.Pulley.

Arm.as.shown ..

8-2

....Choose.any.of.the.four.holes.to.secure .

Slider.Pulley.w/.

Cable.Assembly

Slider.Pulley.w/.

Cable.Assembly

Step 7 Secure.Pulley.Arms

Hardware:

.•...2.Threaded.Studs.(1/2".X.9.1/2")
•...4.Nylock.Nuts.(1/2")
•...4.Washers.(1/2")

tool:

Rubber.Mallet

7-1

...Align.the.two.holes.in.the.

Pulley.Arms.with.those.in.the.
Lower.Lat.Tower.Assembly.and.
secure.using.threaded.studs,.
washers.and.nuts.as.shown .

Flat.Washers

Threaded.

Studs

Nylock.Nuts

Flat.Washers

Assembly Guide
