Bowflex.Xtreme ® .SE.Assembly.Manual
Step 11...Install.Optional..
Leg.Extension.Assembly
parts:
.•...Leg.Extension.Assembly
•...Lock.Knob
11-1 ...Insert.Leg.Extension.
Backbone.into.open.end.of.
Seat.Backbone.as.shown .
11-2 ...Align.one.hole.of.the.Leg.
Extension.with.the.hole.in.
the.Seat.Backbone.to.fit.your.
height.and.secure.with.the.
Lock.Knob.as.shown .
Lock.Knob
Step 12.....Install.Seat.Assembly
parts:
.•...Seat.Assembly
•...Main.Assembly
12-1 ...Align.the.top.two.hooks.on.
the.Seat.Backbone.with.one.
of.the.lower.pairs.of.pins.on.
the.Seat.Support.Rail .
12-2 ...Tip.seat.front.up.and.slide..
hooks.onto.pins ..Rotate.seat.
down.and.back.to.use .
note: ...Use.lower.pins.until.the.seat.
back.is.installed ..Reverse.
procedure.to.remove.seat .
Seat
Backbone
Leg.
Extension.
Backbone
Seat
Backbone
Seat.Support.
Rail
