Filter Anatomy

1

2

3

4

5

6

7

Item #

DescrIptIon

1

Valve

2

Bypass

3

Tank

4

Distributor

5

Filter Media (Calcite, Carbon, or Micro Z™)

6

Faceplate/Controls

7

Gravel Underbed
