9.1 Scope of delivery
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
42
￭￭￭￭￭￭￭￭
867 pH Module
Qty.
Order no.
Description
1
6.2122.0x0
Power supply cable with IEC 60320 line
socket, type C13
Cable plug according to customer requirements.
Switzerland:
SEV 1011, Type 12
6.2122.020
Germany, …:
CEE 7, Type VII
6.2122.040
USA, …:
NEMA 5-15, Type 498
6.2122.070
Length:
1.5 m
1
8.867.8003EN 867 pH Module Manual
9.1.2
2.867.0110
Qty.
Order no.
Description
1
1.854.0010
iConnect
1
1.867.0010
pH Module
1
1.900.0010
Touch Control
1
6.0278.300
iUnitrode with Pt 1000
Combined pH glass electrode for measurements in difficult media,
with memory chip for sensor data such as article and serial number,
calibration data and calibration history.
Shaft material:
Glass
Measuring range:
0 - 14
Measuring unit:
pH
Temperature range, long-
term (°C):
0 - 80
Temperature range, short-
term (°C):
0 - 100
Shaft diameter top (mm):
12
Shaft diameter bottom (mm): 12
Min. immersion depth (mm):
30
Temperature sensor:
Pt1000
Indicator electrode shape:
Cylinder
Membrane glass type:
U
Membrane resistance:
150 - 500
Electrode zero point (mV):
0 - +/-15
Electrode slope:
> 0.97
