￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 3 Installation
803 Ti Stand ￭￭￭￭￭￭￭￭ 13
1 Tubing adapter 6.1808.050 2 Threaded stopper 6.1446.040
3 Overflow protection 6.1623.000 4 PTFE tubing 6.1805.200
5 Stopper 6.1446.090 6 Bottle attachment 6.1602.105
For direct dosing out of reagent bottles with
GL 45 thread.
7 Cannula 6.1819.050 8 Amber glass bottle 6.1608.030
Waste bottle.
9 PVC tubing 6.1801.120 10 Aspiration tip 6.1543.120
11 Connection nipple for PVC tubing
For aspirating the titration vessel content.
12 PTFE tubing 6.1805.200
13 Transfer tip 6.1543.110 14 Connection nipple for PVC tubing
For aspirating solvent.
15 PVC tubing 6.1801.120 16 Threaded stopper 6.1446.040
17 Bottle attachment 6.1602.105
For direct dosing out of the reagent bottle
with GL 45 thread.
18 Amber glass bottle 6.1608.023
Solvent bottle
19 SGJ clip 6.2023.020 20 Adsorber tube with tubing nipple
6.1609.010
21 Cotton 22 Molecular sieve 6.2811.000
23 Cannula 6.1819.030
Mounting the equipment for aspirating
Mount the waste bottle as follows:
1 Equip the 6.1602.105 bottle attachment with the 6.1446.040 threa-
ded stopper, the 6.1808.050 tubing adapter and the 6.1446.090
stopper.
2 Plug the 6.1623.000 overflow protection from below into the
6.1602.105 bottle attachment (the opening, the 6.1808.050 tubing
adapter is plugged in).
3 Screw the 6.1602.105 bottle attachment onto the 6.1608.030 waste
bottle.
4 Cut the 6.1801.120 PVC tubing into two halves and use one to aspi-
rate.
