2 Device overview
￭￭￭￭￭￭￭￭ 7
7 Rotary wheel
For setting the stirring rate. If the end of the
scale is reached, turn to the other end in
order to readjust the scale. 8 Clamping screw
For fixing the positioning height of the
6.2137.000 rotary controller on the support
rod.
9 Connector plug
For connecting the propeller stirrer. 10 Connector plug
For connecting a power supply:
EU 230V / 9V DC
USA 110V / 9V DC
