Page 10
Duo-FireWire Installation and User’s Manual
3. Overview
The PRO / Duo-FireWire supports the latest FireWire 800 interface and the latest
USB 2.0 interface. The FireWire 800 is backward compatible with the FireWire
400 and the USB 2.0 is backward compatible with the USB 1.1 / 1.0.
3.1. The Classic and PRO look
The newer PRO Duo-FireWire has exactly the same performance and operation
specification as the original classic Duo-FireWire, except the PRO has a new
finish. The PRO Duo-FireWire has a darker, shiny, smooth brushed finished,
where the classic Duo-FireWire has a textured gray paint finish.
Duo-FireWire PRO Duo-FireWire
The Classic look The PRO look
3.2. Front Indicators
Indicators
Power (white)
DISK 1 Active (blue)
DISK 2 Active (blue)
Page 11
Duo-FireWire Installation and User’s Manual
3.3. Rear Panel
FireWire 800 Ports USB 2.0 Port
Security Slot
Power Source
Power on / off
Cooling Fan Operating Mode
