3G-TPG OPERATING MANUAL

www.decimator.com

PATTERN: (Has SUB‐MENU with parameter)
This is the currently selected test pattern.
When selected in the Menu Window, the PATTERN is displayed in the Parameter Window.
When highlighted, press the ENTER button to enter this sub‐menu.
Press the < and > buttons to move left or right through the 54 test patterns listed below and
the BACK button to leave this SUB‐MENU.

1. SMPTE HD Bars

19. Convergence

37. Y Moving Down Y ZP

2. Bars 100/0/100/0

20. Tartan Bars

38. Y Moving Up XY ZP

3. Bars 100/0/75/0

21. 1 Field in 8 White

39. Y Moving Down XY ZP

4. Bars 75/0/75/0

22. White 100%

40. Y Static C ZP

5. Bars 100% & Red

23. White 75%

41. Y Moving In C ZP

6. SMPTE EG 1 Bars

24. Black

42. Y Moving Out C ZP

7. Path Equalizer & PLL

25. Red

43. UV Static X ZP/L

8. Square on 4:3 Mon.

26. Yellow

44. UV Static X ZP/H

9. Square on 16:9 Mon.

27. Green

45. UV Static Y ZP

10. 5 Step Y Staircase

28. Blue

46. UV Moving Left X ZP

11. 5 Step UV Staircase

29. Magenta

47. UV Moving Right X ZP

12. Y Sweep

30. Cyan

48. UV Moving Up Y ZP

13. UV Sweep

31. Y Static X ZP/L

49. UV Moving Down Y ZP

14. Y Multiburst

32. Y Static X ZP/H

50. UV Moving Up XY ZP

15. UV Multiburst

33. Y Static Y ZP

51. UV Moving Down XY ZP

16. Y Ramp

34. Y Moving Left X ZP

52. UV Static C ZP

17. UV Ramp

35. Y Moving Right X ZP

53. UV Moving In C ZP

18. Pluge

36. Y Moving Up Y ZP

54. UV Moving Out C ZP
