Cyclopital3D Fuji W3 Stereo Base Extender - Manual (Page 2)

Instructions for use:
1. Slide lens cover open.
2. Insert camera into adapter.
3. Attach to camera by inserting thumb screw into the tripod mount.
4. Turning your camera on (and off). If the camera is off, press and
hold the “play” button in the middle of the control panel. The
camera will power up in playback mode, switch to camera mode
by half pressing the shutter button. To turn the camera off, press
the play button once which will return it to playback mode, then
press and hold the play button until camera turns off.
5. Adjust the zoom. When the camera is first turned on, the lens
will be at minimum zoom. To use the adapter you will need to
zoom in until there are no obstructions seen on the display- you
will see the black sides of the adapter until it is appropriately
zoomed in.
When using a flash:
• The flash hot shoe will
accommodate almost
any kind of flash unit
that has a hot shoe
adapter.
• The camera must be
set to “forced flash”.
• Red-eye removal in set-up menu must be OFF.
• Set the camera to manual mode, set ISO, aperture and shutter
speed to appropriate values for the lighting making sure that the
flash is set with identical values.
• It is recommended to use the flash in auto mode, with the same
values as your camera.
• Note: because an additional battery is not needed to power the
flash control unit, it does not work with some older, high-voltage
flash models. A list of known compatible flash models is being
updated continuously and is posted at www.cyclopital3d.com.
Portable 3D Viewing OpƟons!
Digital 3D Photo Viewer
Holds thousands of images!
Lighted Print Viewer
No more searching for the right lighƟng with
built in LED lights!
All rights reserved, Cyclopital3D, Inc. 2010
