Instructions for use:

1. Slide lens cover open.

2. Insert camera into adapter.

3. Attach to camera by inserting thumb screw into the tripod mount.

4. Turning your camera on (and off). If the camera is off, press and

hold the “play” button in the middle of the control panel. The
camera will power up in playback mode, switch to camera mode
by half pressing the shutter button. To turn the camera off, press
the play button once which will return it to playback mode, then
press and hold the play button until camera turns off.

5. Adjust the zoom. When the camera is first turned on, the lens

will be at minimum zoom. To use the adapter you will need to
zoom in until there are no obstructions seen on the display- you
will see the black sides of the adapter until it is appropriately
zoomed in.

6. Put your camera into macro mode to improve its ability to set

auto-parallax on the close-up scene, by pressing the left selector
button (flower symbol) twice."

When using a flash:

The flash hot shoe will accommodate almost any kind of flash unit
that has a hot shoe adapter.

The camera must be set to “forced flash”.

Red-eye removal mode must be OFF.

Set the camera to manual mode, set ISO, aperture and shutter
speed to appropriate values for the lighting making sure that the
flash is set with identical values.

It is recommended to use the flash in auto mode, with the same
values as your camera.

Note: because an additional battery is not needed to power the
flash control unit, it does not work with some older, high-voltage
flash models. A list of known compatible flash models is being
updated continuously and is posted at www.cyclopital3d.com.

Expand the PotenƟal of your Fuji W3!

Auxiliary Lens Adapter

Use with 37mm wide angle and fish-eye lenses

Base Extender

Increases stereo base to 225mm!

Perfect for wildlife, landscapes and band or wedding photos.

All rights reserved, Cyclopital3D, Inc. 2010

Cleaning and Maintenance

The microscope cover glass used on the inside of the adapter to seal
the mirror chamber is thin and fragile. If it becomes necessary to clean
the delicate glass, use a Q-tip wetted with alcohol, very gently. To gain
access to the front, simply unscrew the UV filter and access the glass
from the front. Do not attempt to remove the microscope cover glass
because it WILL break.

Warranty

Your adapter comes with a Limited Warranty against defects in
workmanship and materials for 90 days from the date of purchase. The
limited warranty does not apply if the product has been damaged by
accident, mishandling, misuse, abuse, or alteration.
