6 •
PCoIP
I9420 and I9440 I/Ports use PCoIP technology to deliver high–performance video and audio to
users. PCoIP technology consists of dedicated processors on the thin client (I94xx I/Port) and
on the host to which the thin client connects. ClearCube hosts can support I94xx I/Ports by
using one of the following host–side cards:
• V5120 Dual Host card—Contained in specific A–series and R–series PC blades to
support I9420 I/Ports
• V5140 Quad Host card—Contained in specific A–series PC blades to support I9440
I/Ports
Figure 2. Typical I94xx architecture
Chassis and Blades
DHCP
Network Switch
I94xx I/Port
