• 21
Table 1. I8330 Setup Tabs
Option Description
Network Tab
IP Address This radio-button menu specifies IP Addressing mode. Choices include:
• Get Dynamic IP Address
• Get Static IP Address
The default selection is Get Dynamic IP Address. When Static IP Address mode is chosen, the
administrator can specify the IP address and IP Gateway for this I8330 I/Port.
MAC Address This static field specifies the MAC Address for this I8330 I/Port.
Options Tab
Connection Mode This radio-button menu specifies the Connection mode. Choices include:
• Direct Connection
• Sentral
The default selection is Direct Connection. When Direct Connection is chosen with
Autodetection, the I8330 I/Port lists the first eight hosts it locates that have the I83xx Driver
installed, and that are available for a connection. The user can log into one of these hosts if user
credentials are available.
NOTE: The I8330 discovers hosts non-deterministically. If your network has more than eight
hosts with the I83xx Driver installed, the I8330 will not always list the same eight hosts in the login
selection dialog box.
When Sentral is chosen with Autodetection, the I8330 I/Port searches for a Sentral Console
for its login management. If one is found, a Sentral login dialog box is displayed.
Server Connection
List The default selections include:
• Autodetection
• TS 2
• TS 3
The default active connection is Autodetection. This selection’s name cannot be edited. The
names of the other two choices can be edited. To activate or deactivate a connection, highlight it
in the list and click the Enable/Disable button. To edit a connection, highlight it and click the
Edit button.
Edit Connection Profile Dialog
Connection name This editable field specifies the name of the specified connection.
Autoconnect Enabled This button allows turning on Autoconnect. The default is Off (unchecked). If Enabled
(checked), the I8330 automatically connects to the system whose IP address is entered in the
Server Network Address field.
Server Network
Address This editable field specifies the IP address of a host to which the I8330 automatically connects.
The I83xx Driver or the I83xx Admin Utility must be installed on this host for a connection to be
made. If the I83xx Driver is installed, the connection is a direct connection. If the I83xx Admin
Utility is installed, a Sentral login is displayed.
User name This editable field specifies the user name for this I8330. Entry is optional.
