About the ClientCube 2 Mounting Bracket,
Continued
Assembled
brackets The pictures below show assembled brackets (figure 1) and the mounting bracket installed
below a desk with a ClientCube 2 (figure 2).
Figure 1. Mounting bracket with keeper bracket latched in place
Figure 2. ClientCube 2 mounted under a desk
