Find the slope of a pipe Run if it drops 6 Inches
over 50 Feet. What is its Angle and Percent Grade?

KEYSTROKES

DISPLAY

 

0.

 

RUN 50

FEET

0

INCH

 

OFST 6

INCH

 

% GRD 1.

GRD 0.01

SLP 0

FEET

1/8

INCH

/Ø 0.57º

Calculate Pipe Length for a Rolling Offset with
a 4” Roll, 5” Offset and a 45º Fitting Angle.

KEYSTROKES

DISPLAY

 

0.

/Ø 45.00 º

 

OFST 5

INCH

  

LNTH 9 1/16

INCH

Continue pressing the Travel key to view all
related values.
(setback)

STBK 0

FEET

6-3/8

INCH

BEND 45.00 º

OFST 5

INCH

ROLL 4

INCH

If a pipe Run requires 1/8” drop per foot for
drainage, how much total drop is required for
a 25’ Run?
