Calculated Industries 4065 v3.1 Pocket Reference Guide Advanced Consnruction-Math User Manual

Page 26

background image

P

OCKET

R

EFERENCE

G

UIDE

— 22

Squaring-Up a Foundation

Square-up a 4700 mm x 3100 mm
foundation:*

KEYSTROKE

DISPLAY

o o

0.

4 7 0 0 Ç 9 l LNTH 4700.

MM

3 1 0 0 Ç 9 W WDTH 3100.

MM

W W

SQUP 5630.

MM

*Alternative Method

Square-up a 4700 mm x 3100 mm
foundation:*

KEYSTROKE

DISPLAY

o o

0.

4 7 0 0 Ç 9 R

RUN 4700.

MM

3 1 0 0 Ç 9 r RISE 3100.

MM

d

DIAG 5630.

MM
