Close the hinged pistol housing (#8) and push in the
front housing end cap (#6) and rear housing end cap (#7)
IMPORTANT : While closing the front & rear housing end caps
make sure both locking pins are fully out. Completely reinsert
forward and rear locking pins.
(Applicable only to full size pistol) Tighten the barrel
shroud set screw
(#10) insuring the barrel shroud covers (#6)
the barrel muzzle. This can be visually checked by closing the
forward housing end cap while the hinged pistol housing is
open
(#8) . (Reopen front housing end cap)
Step 7.
Open hinged pistol housing of the RONI by gently pulling
from the inside at the top of the hinged pistol housing
(#8) . It will easily open outwards.
Step 5.
MAKE SURE YOUR PISTOL IS UNLOADED AND THE
CHAMBER IS EMPTY Install the charging handle over the
rear sight of the pistol. The charging handle
(#13) fits over
the rear sight and grasps the slide serrations on the dust
cover (slide) of the pistol.
Step 6.
Step 9. Step 10.
9
Install the pistol inside the hinged pistol housing, making
sure it is laying flat. Proper positioning will insure:
(a)
The under barrel rail slot on the pistol is engaged in
the male rail bar on the RONI.
(b) The trigger guard is
mated to the trigger guard housing in the RONI housing.
(c) Pistol tang mates to tang cutout in RONI housing.
Forward Locking Pin
Rear Locking Pin
Vertical Forward Grip Removal Button
Vertical Forward Grip
Vertical Forward Grip Position Selection Button
Forward Barrel Housing End Cap
Rear Housing End Cap
Hinged Pistol Housing
Trigger Guard
Muzzle Shroud Screw
Adjustable Cheek Piece
Extra Magazine Holder
Charging Handle
Stock Extension Button
Adjustable Cheek Piece Screw
Muzzle Shroud
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
13
WARNING: If you actually possess, or constructively possess, a
pistol and the RONI device, even if the pistol is not assembled into
the RONI device, the combination would constitute a short barreled
rifle, which may not be lawfully possessed unless it is registered
in the National Firearms Registration and Transfer Record You
are in constructive possession of an object if you have dominion
and control over it, whether or not you are actually handling it.
Provided by our legal counsel. s
8
a
b
c
Step 8.
(Applicable only to full size pistol) Installation requires the
barrel shroud screw
(#10) in the lower rail be loosened until
the barrel shroud (#16) will move. The barrel shroud has
two threaded holes for the barrel shroud screw. Reposition
the barrel shroud in the second hole (increasing the overall
length of the RONI) so it is in contact with full size pistol
barrel muzzle face when you close the forward housing end
cap
(#6) .
Bottom View
10
16
6
10
8
1
8
7
2
9
6
upgrade your weapon
roni parts
WARNING: Always keep the trigger guard positioned over the trigger
unless shooting to prevent the trigger from being activated
RONI assembly instructions
1-866-611-9576 / WWW.COMMANDARMS.COM
215-949-9944 / WWW.EMATACTICAL.COM
Lubricate as Necessary
7
12
8
2 11
15
14
13
1
6
16
5
10
3
9
4
