Bully Dog 52101 Rapid Flow Induction - Manual (Page 5)

RAPID FLOW INDuCTION
INSTALLINg ThE rFI
1. Set the RFI filter housing into the engine bay.
Line up the metal posts on the bottom of filter
housing to the post holes in the engine bay.
3. Connect the intake hose over the RFI Outlet
Secure the connection using a flat head screw-
driver.
4. Insert the Mass Air Flow sensor into the air
sensor hole on the RFI outlet. Secure the MAF
sensor using the two replacement screws with
a phillips screw driver.
5. Locate the swing arm and the 10mm nut in-
cluded with the RFI. Install rubber grommet
from the stock intake arm. into the hole at the
end of the swing-arm of the new RFI.
6. Place the swing arm over the anchor bolt above
the passenger side headlight just like the stock
intake, and then attach the other end to the
threaded stud on the intake filter housing.
Secure the swing arm using the nut from the
stock system and the nut that is included with
the RFI, both are 10mm nuts.
7. Place the air filter onto the outlet tube inside
the filter housing. Secure the filter using a flat
head screw driver to tighten the provided band
clamp around the end of the filter.
8. Finally place the lid over the filter housing and
secure the lid using the black button on the
intake lid.
