brite-View Air SyncHD BV-2322 User Manual - Manual (Page 20)

19
(8) If all operation is normal, the POWER LED and SOURCE LED will glow in solid blue. Please refer
to the next form containing detailed LED description :
Note:
A. Make sure your high-definition audio/video devices connected to the BV-2322T has
already been powered on.
B. Warming-up or source switching time should take approximately 20~30 seconds if the
operation is in normal condition.
(9) TRANSMITTER/RECEIVER Status Indicator LED Light and OSD :
Status indicator LED light on the front display the following messages:
Power LED Source LED Mode Status Description OSD Display
Static Purple
on TX
Static Red on
RX
Static Blue
on TX
Off on RX
Listen
To lower power
consumption;
“Loop through” display
always on. Please refer Section
2.2, paragraph C &
D for detailed
description.
Static Red Off Standby
For the lowest power
saving used.
Please refer Section
2.2, paragraph C &
D for detailed
description.
Blinking Blue Blinking
Initial
Boot up
System boot up and RF
linking automatically. Searching available
channels…
Blinking Blue Blinking
Booting
and Linking
RF linking
Searching available
channels…
Static Blue
Blinking
3 times /sec.
(Quickly)
Linked
No input detected from
selected source.
No Signal
Blinking
1 time / sec.
(Slowly)
Video frame rate or
resolution cannot be
recognized. (Not
supported or out of
range.)
No Supported
Format.
Static Blue
Video frame rate or
resolution is recognized.
Transmission is available
with stable RF signal.
