Blizzard Lighting Kontrol 6(Rev. A) - Manual (Page 18)

KONTROL 6 Manual Rev B.
Page 18
© 2014 Blizzard Lighting, LLC.
ALL RIGHTS RESERVED
4.5 TECH SPECS!
Weight & Dimensions
Length
10.2 inches (255 mm)
Width 5.6 inches (142 mm)
Height 2.75 inches (69.5 mm)
Weight 3.25 lbs (1.5 kg)
Power
Operating Voltage
9-12 VDC, .3A (From included power supply)
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 192
Output 3-pin XLR Female
USB Data Format
USB Specification
1.0
Disk Format FAT16 / FAT32 ONLY
Maximum Disk Size 4GB
Other Information
4 in every 8 math teachers think that they should be 1 in every 2 math teachers.
Warranty
2-year limited warranty.
