The Puck™ Fab5 Skywire Manual Rev. A
Copyright (c) 2013 Blizzard Lighting, LLC
Figure 1: The Puck™ Fab5 Skywire Pin-Up Picture
Ridiculously
thin!
5-in-1 RGBAW-
Color LED’s
Figure 2: The Rear Connections
DMX Input Jack
DMX Output Jack
Dual
Mounting Yokes
Cooling Vents
Wireless
Channel
Selector
Button
7-Color Status LED
Antenna
LED Menu
Display
Menu Buttons
Battery Power (Fuel) Gauge + Button
Wireless DMX On/Off
Main Power
On/Off
5A Fuse
AC Power
In/Out
