Restore Default Settings
This will restore all of the default settings including pan/tilt reversal and the starting DMX address.
1.) Navigate the menu using the
2.) Push the button.
3.) Use the buttons to select either dF0F (No) or dF0n (Yes).
4.) Press the button to confirm.
Pan/Tilt Motor Reset
1.) Navigate the menu using the
2.) Press the button to confirm.
DMX Values In-Depth (13-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Pan (0-540°)
2 000 <--> 255 Tilt (0-270°)
3 000 <--> 255 Fine Pan (fast <--> slow)
4 000 <--> 255 Fine Tilt (fast <--> slow)
5 000 <--> 255 Pan/Tilt Speed (slow <--> fast)
6 000 <--> 255 Dimmer (0% <--> 100%)
7 000 <--> 255 Strobe (slow <--> fast)
8 000 <--> 255 Red Intensity (0% <--> 100%)
9 000 <--> 255 Green Intensity (0% <--> 100%)
10 000 <--> 255 Blue Intensity (0% <--> 100%)
11 000 <--> 255 White Intensity (0% <--> 100%)
12
000 <--> 010
011 <--> 020
021 <--> 030
031 <--> 040
041 <--> 050
051 <--> 060
061 <--> 070
071 <--> 080
081 <--> 090
091 <--> 100
101 <--> 110
111 <--> 120
121 <--> 130
131 <--> 140
141 <--> 150
151 <--> 160
161 <--> 200
201 <--> 240
241 <--> 255
Built-in Programs, Sound Active
No Function
Red
Green
Blue
White
Red+Green
Green+Blue
Blue+White
Red+White
Red+Blue
Green+White
Red+Green+Blue
Green+Blue+White
Red+Blue+White
Red+Green+White
Red+Green+Blue+White
Color Snap (Slow <--> Fast)
Color Fade (Slow <--> Fast)
Sound Active Mode
13
000 <--> 149
150 <--> 200
201 <--> 255
No Function
Motor Reset
No Function
