Figure 1: The StormChaser™ Pin-Up Picture
High Power
LED’s
Anodized Aluminum
Enclosure
Mounting Bracket &
Adjustment Screw
Figure 2: The Rear Connections
MENU UP DOWN ENTER
AC Power In
AC Power Out
DMX In DMX Out
LED Display Menu Menu Buttons
Microphone
Left
End
Right
End
