StormChaser Manual Rev. C Copyright (c) 2012 Blizzard Lighting, LLC
2. MEET THE STORMCHASER™
CONTROL FEATURES
• Powered by 252 high power 10mm Red/Green/Blue/White LEDs
• Variable electronic strobe
• 4 DMX modes for ultimate control flexibility
• Super flexible design allows for use as an effect/chase light or as a
7-pixel RGBW display device
• Built-in color & chase macros via DMX
• Built-in auto & sound activated programs via master/slave & DMX
ADDITIONAL FEATURES
• Compact and lightweight (it kept its new year’s resolution!)
• Lux: ~3,250 @ 1m
• Very low power consumption, high output
• IEC output for power link
• 4-button LED display on rear panel
• Static colors and RGBW color mixing
DMX Quick Reference - 31 Channel Mode
Channel What It Does
1
DMX Mode Selection
2 Dimmer (0 <-->100%)
3 Strobe (Slow <--> Fast)
4 -31 Individual Pixel Color Intensity
DMX Quick Reference - 10/7 Channel Mode
Channel What It Does (10-ch.) Channel What It Does (7-ch.)
1 DMX Mode Selection 1 DMX Mode Selection
2 Dimmer (0 <-->100%) 2 Dimmer (0 <-->100%)
3 Strobe (Slow <--> Fast) 3 Strobe (Slow <--> Fast)
4 Pixel 1 Global Intensity 4 Global Red Intensity
5 Pixel 2 Global Intensity 5 Global Green Intensity
6 Pixel 3 Global Intensity 6 Global Blue Intensity
7 Pixel 4 Global Intensity 7 Global White Intensity
8 Pixel 5 Global Intensity -- --
9 Pixel 6 Global Intensity -- --
10 Pixel 7 Global Intensity -- --
DMX Quick Reference - 2 Channel Mode
Channel What It Does
1
Built-in Programs
2 Speed Control
