Page 19
G70™ Moving Head Spot - Rev. A (c) 2014 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Width
13.3 inches (341 mm)
Depth 10.5 inches (265 mm)
Height 21.5 inches (546 mm)
Weight 33.1 lbs (15 kg)
Power
Operating Voltage
90-260VAC 50/60Hz (autoranging)
Power Consumption 119w, 1.58a, pf:.61
Fuse 3A, 250V
Light Source
LED
70W (7* 10W) CREE® LED Source
Optical
Beam Angle
15 degree
Luminous Intensity 45,300 Lux @ 1m | 8,300 Lux @ 2m
Movement Range
Pan
540 degrees
Tilt 270 degrees
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol
USITT DMX-512
DMX Channels 11/14 channel
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Information
For the price of just one cup of coffee you can feed a child a coffee.
Warranty
2-year limited warranty, does not cover malfunction caused
by damage to LED’s.
DISCLAIMER:
The power connector fitted to the fixture and fixture cord are designed for compatibility
with products manufactured by Neutrik AG, Neutrik USA and their related entities, how-
ever they are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik
USA, or any related entity. Neutrik® and powerCON® are registered trademarks of
Neutrik AG.
