G70™ Moving Head Spot - Rev. A (c) 2014 Blizzard Lighting, LLC
Control Panel Menu Structure
Main Function Sub Function Selection What It Does...
Address N/A 001 <-> 512 Sets the DMX address
System Channel Mode Standard 14-Channel DMX Mode
Reduced 11-Channel DMX Mode
Extended Same as standard mode, reserved for future use.
Language English English Language
中文 Chinese Language
Manual Lamp Control Turn on Reserved for future use, no function.
Turn off Reserved for future use, no function.
Lamp Power Full power Reserved for future use, no function.
Half power Reserved for future use, no function.
Reset Head Reset Reset the color & gobo wheels
P-T Reset Reset the pan & tilt motors
System Reset Full fixture reset
Channel Strobe Strobe Rate (slow <--> fast), 000 = Lamp On
Dimmer Dimmer (0% <--> 100%)
Color Color Wheel (000-255), see DMX values (p.14)
Gobo 1 Gobo Wheel 1 (000-255), see DMX values (p.14)
Gobo 2 Gobo Wheel 2 (000-255), see DMX values (p.14)
Gobo 2 Rotation Gobo 2 Rotation (slow <--> fast)
Prism Prism Effect (000-255), see DMX values (p.14)
Focus Focus (0% <--> 100%)
Pan Pan Adjustment (000-255)
Tilt Tilt Adjustment (000-255)
Run Mode Auto Program 1 OK / Cancel Set the fixture to run Auto 1
Auto Program 2 OK / Cancel Set the fixture to run Auto 2
Auto Program 3 OK / Cancel Set the fixture to run Auto 3
Sound Mode OK / Cancel Set the fixture to run in Sound Active Mode
DMX512 Mode OK / Cancel Set the fixture to run in DMX Mode
Option Pan/Tilt Invert Pan Invert pan
Invert Tilt Invert tilt
Swap Pan-Tilt Invert the pan and tilt
Curve Curve 1 Reserved for future use, no function.
Curve 2 Reserved for future use, no function.
Curve 3 Reserved for future use, no function.
Display Normal Normal LCD display
Turn Over Flip the LCD display
Information --- Software version / DMX channel display
