G70™ Moving Head Spot - Rev. A

Clamp Mounting

This fixture provides a mounting bracket assembly that secures the

bottom of the base, the “Omega Brackets,” and the safety cable

rigging point together. When mounting this fixture to truss, be sure to

secure an appropriately rated clamp to the omega bracket using an

M10 screw fitted through the center hole of the “omega bracket”.

Securing the Fixture

Regardless of the rigging option you choose for your fixtures always be

sure to secure your fixture with a safety cable. Be sure to only use the

designated rigging point found on the underside of the base assembly

for the safety cable. Never secure a safety cable to a carrying handle.

1.) Clamp

2.) Omega Bracket

3.) ¼ Turn Quick Lock Fasteners
