CobZilla™ COB RGB 5X5 Pixel Matrix Manual Rev. A Copyright (c) 2010-14 Blizzard Lighting, LLC
DMX Quick Reference (75-Channel Mode)
Individual Pixel Control Dimmer 0%-100%
CH 1 CH 2 CH 3 CH 4 CH 5 CH 6
Pixel 1 Red Pixel 1 Blue Pixel 1 Green Pixel 2 Red Pixel 2 Blue Pixel 2 Green
CH 7 CH 8 CH 9 CH 10 CH 11 CH 12
Pixel 3 Red Pixel 3 Blue Pixel 3 Green Pixel 4 Red Pixel 4 Blue Pixel 4 Green
CH 13 CH 14 CH 15 CH 16 CH 17 CH 18
Pixel 5 Red Pixel 5 Blue Pixel 5 Green Pixel 6 Red Pixel 6 Blue Pixel 6 Green
CH 19 CH 20 CH 21 CH 22 CH 23 CH 24
Pixel 7 Red Pixel 7 Blue Pixel 7 Pixel 8 Red Pixel 8 Blue Pixel 8 Green
CH 25 CH 26 CH 27 CH 28 CH 29 CH 30
Pixel 9 Red Pixel 9 Blue Pixel 9 Green Pixel 10 Red Pixel 10 Blue Pixel 10 Green
CH 31 CH 32 CH 33 CH 34 CH 35 CH 36
Pixel 11 Red Pixel 11 Blue Pixel 11 Green Pixel 12 Red Pixel 12 Blue Pixel 12 Green
CH 37 CH 38 CH 39 CH 40 CH 41 CH 42
Pixel 13 Red Pixel 13 Blue Pixel 13 Green Pixel 14 Red Pixel 14 Blue Pixel 14 Green
CH 43 CH 44 CH 45 CH 46 CH 47 CH 48
Pixel 15 Red Pixel 15 Blue Pixel 15 Green Pixel 16 Red Pixel 16 Blue Pixel 16 Green
CH 49 CH 50 CH 51 CH 52 CH 53 CH 54
Pixel 17 Red Pixel 17 Blue Pixel 17 Green Pixel 18 Red Pixel 18 Blue Pixel 18 Green
CH 55 CH 56 CH 57 CH 58 CH 59 CH 60
Pixel 19 Red Pixel 19 Blue Pixel 19 Green Pixel 20 Red Pixel 20 Blue Pixel 20 Green
CH 61 CH 62 CH 63 CH 64 CH 65 CH 66
Pixel 21 Red Pixel 21 Blue Pixel 21 Green Pixel 22 Red Pixel 22 Blue Pixel 22 Green
CH 67 CH 68 CH 69 CH 70 CH 71 CH 72
Pixel 23 Red Pixel 23 Blue Pixel 23 Green Pixel 24 Red Pixel 24 Blue Pixel 24 Green
CH 73 CH 74 CH 75
Pixel 25 Red Pixel 25 Blue Pixel 25
