CobZilla™ COB RGB 5X5 Pixel Matrix Manual Rev. A Copyright (c) 2010-14 Blizzard Lighting, LLC
2. MEET THE COBZilla™ COB RGB 5X5 Pixel Matrix
CONTROL FEATURES
• 25 individually controllable COB (Chip-On Board) RGB LED’s
• Variable electronic strobe
• Variable electronic dimmer
• Built-in automated programs via master/slave
• Sound Active via DMX
• Easy to use 4 button LCD Control Panel
ADDITIONAL FEATURES
• Very Rugged and well-built (yea, it works out alot)
• Lux: 12,100 @ 1m, 4,600 @ 2m
• Light source: 25 x 9 watt 3-in-1 COB LED’s
• PowerCon
™
Compatible Power In/Out
• 1/2-turn coffin-lock fixture link brackets
• 3-pin & 5-pin DMX In/Out
DMX Quick Reference (3-Channel Mode)
Channel What It Does
1 Built-in Programs
2 Program Speed
3 Strobe
DMX Quick Reference (5-Channel Mode)
Channel What It Does
1 Red 0%-100%
2 Green 0%-100%
3 Blue 0%-100%
4 Master Dimmer 0%-100%
5 Strobe
