CobZilla™ COB RGB 5X5 Pixel Matrix Manual Rev. A

Copyright (c) 2010-14 Blizzard Lighting, LLC

DMX Values In-Depth (3-Channel Mode)

Channel

Channel Value

Does...

1

000

001 <-> 012

013 <-> 025

026 <-> 038

039 <-> 051

052 <-> 064

065 <-> 077

078 <-> 090

091 <-> 103

104 <-> 116

117 <-> 129

130 <-> 142

143 <-> 155

156 <-> 168

169 <-> 181

182 <-> 194

195 <-> 207

208 <-> 220

221 <-> 233

234 <-> 255

Built-in Programs

Off

Program 1

Program 2

Program 3

Program 4

Program 5

Program 6

Program 7

Program 8

Program 9

Program 10

Program 11

Program 12

Program 13

Program 14

Program 15

Program 16

Program 17

Program 18

Sound Active

2

000 <-> 233

234 <-> 255

Speed of Program

Sensativity for Sound Active Mode

3

000 <-> 233

234 <-> 255

Strobe Rate

No function in Sound Active Mode

DMX Values In-Depth (5-Channel Mode)

Channel

Channel Value

Does...

1

000 <-> 255

Red Dimmer 0%-100%

2

000 <-> 255

Green Dimmer 0%-100%

3

000 <-> 255

Blue Dimmer 0%-100%

4

000 <-> 255

Master Dimmer 0%-100%

5

000 <-> 255

Strobe Rate 0%-100%
