Blade™ QFX User Manual Rev. A
(c) 2013 Blizzard Lighting, LLC
DMX Values In-Depth (25-Channel Mode)
Channel
Value
What It Does
1
000 <--> 255 Pan
2
000 <--> 255 Pan Trim (16-bit)
3
000 <--> 255 Tilt
4
000 <--> 255 Tilt Trim (16-bit)
5
000 <--> 255 Pan/Tilt Speed (Fast <--> Slow)
6
000 <--> 255 Dimmer (0% <--> 100%)
7
000 <--> 009
010 <--> 089
090 <--> 169
170 <--> 249
250 <--> 255
No Function
Strobe (Slow <--> Fast)
Random Strobe
Strobe with color changing
No Function
8
000 <--> 255 Built-in Programs
9
000 <--> 255 Built-in Program Speed (0% <--> 100%)
10
000 <--> 255 1st LED Group - Red Intensity (0% <--> 100%)
11
000 <--> 255 1st LED Group - Green Intensity (0% <--> 100%)
12
000 <--> 255 1st LED Group - Blue Intensity (0% <--> 100%)
13
000 <--> 255 1st LED Group - White Intensity (0% <--> 100%)
14
000 <--> 255 2nd LED Group - Red Intensity (0% <--> 100%)
15
000 <--> 255 2nd LED Group - Green Intensity (0% <--> 100%)
16
000 <--> 255 2nd LED Group - Blue Intensity (0% <--> 100%)
17
000 <--> 255 2nd LED Group - White Intensity (0% <--> 100%)
18
000 <--> 255 3rd LED Group - Red Intensity (0% <--> 100%)
19
000 <--> 255 3rd LED Group - Green Intensity (0% <--> 100%)
20
000 <--> 255 3rd LED Group - Blue Intensity (0% <--> 100%)
21
000 <--> 255 3rd LED Group - White Intensity (0% <--> 100%)
22
000 <--> 255 4th LED Group - Red Intensity (0% <--> 100%)
23
000 <--> 255 4th LED Group - Green Intensity (0% <--> 100%)
24
000 <--> 255 4th LED Group - Blue Intensity (0% <--> 100%)
25
000 <--> 255 4th LED Group - White Intensity (0% <--> 100%)
