6150-com
SB II Series Signal Booster
Remote Communication Card
6150-COM
COMPLETE REMOTE ACCESSIBILITY
}
Remote configuration and gain level adjustment.
}
Remote retrieval of 100 day OLC Datalog information.
}
Remote alarm and status monitoring.
}
Remote loading of software updates, revisions.
}
Data Ports: RS232 Port accommodates direct connection to
local PC.
}
RJ45 Port provides 10 Base T interface to private networks,
internet or wireless (WiFi) networks.
}
TCP/IP Network Protocol Compatibility Static or DHCP assigned
IP address.
}
HTTP 1.0/1.1 web compatible provides complete functionality
using common web browsers.
}
Currently supports FTP firmware update, email alert feature
available in future software release.
No PC Based Proprietary Software Required
REMOTE CONFIGURATION OF CRITICAL
OPERATING PARAMETERS
Calibrate amplifier current to eliminate erroneous alarms.
Adjust gain via attenuation or bypass amplifiers when OLC
datalog indicates consistent, strong signal activity through
booster.
Configure desired output power.
TX RX Systems Brand
