Maintenance
20
Replacement Parts
Front Connector Parts Assigned Per Model Type:
Model 8745 - 3-1/8" EIA Connector 50 ohms
Model 8746 - 3-1/8" Unflanged Connector Flush Center Conductor 50 ohms
For Both Models
Customer Replacement Part Consists of Description
RPK8755-027-2 8755-027-2 Resistor 50.75 ohm 20kW
923-RPK000 Instruction Sheet
8740-025 8755-025 Inner Flow Tube
8755-024 Outer Flow Tube
8740-020 O-Ring Kit
8755-005 Resistor Cap Assembly
8755-016 Resistor Contact
8755-026 Resistor Holder
923-8740-025 Instruction Sheet
8740-020 5-099 O-Ring #568-116
5-567 O-Ring AS568A-125
5-1127 O-Ring #568-123
5-1128 O-Ring #568-222 Sili
8110-059 O-Ring #568-211
8410-009 O-Ring #568-224
Item Qty Description Part Number
11 1 Center conductor input, assembly 8755-007
12 1 Outer conductor assemblY 8755-004
Item Qty Description Part Number
13 1 Center conductor input, assembly 8756-003
14 1 Outer conductor assemblY 8756-002
Item Qty Description Part Number
15 1 Center conductor assembly O-Ring 5-1127
16 6 Socket head cap screws,
1/4-20 x 1", stainless steel
1121-1508-00
17 1 lnner resistor cap seal O-Ring 5-567
